Combination Of Ultrafiltration Membrane Filaments Ultrafiltration Equipment Industry Wastewater Treatment
Brief Introduction
Located in Yixing, an advanced and beautiful city of Jiangsu Province, China, Longdai Co., Ltd is a processing equipment supplier of petrochemical industry specialized in environmental processing &integrating independent research and development, design, general contracting, environmental protection equipment manufacturing, and relevant material supply.
Description
The form of ultrafiltration membrane can be divided into two types: plate type and tube type. Tubular ultrafiltration membranes are divided into hollow fiber, capillary and tubular typ according to their different diameters. The ultrafiltration membranes used in the market for water treatment are basically capillary type. The hollow fiber (inner diameter 0.1-0.5mm) polyethylene or polypropylene microporous membranes used in individual projects should actually be microfiltration membranes.
Application
Ultrafiltration membranes are widely used in water treatment projects. Ultrafiltration technology is playing an increasingly important role in the fields of reverse osmosis pretreatment, drinking water treatment, and water reuse. Ultrafiltration technology plays a key role in the sterilization and turbidity removal of alcohol and beverages, the removal of pyrogens of medicines, and the concentration of food and medicines.
Parameters
| Type | Inlet Pipe | Outlet Pipe | Cleaning Pipe | Overflow pipe | D | F | G | K | L | S |
| ZL350X600 | DN100 | DN150 | DN15 | DN80 | 880 | 620 | 600 | 540 | 760 | 735 |
| ZL610X610 | DN150 | DN200 | DN15 | DN80 | 1385 | 750 | 1000 | 630 | 885 | 748 |
| ZL610X1220 | DN200 | DN250 | DN20 | DN150 | 1385 | 950 | 1000 | 830 | 1085 | 1360 |
| ZL610X1830 | DN250 | DN300 | DN25 | DN150 | 1385 | 1100 | 1000 | 980 | 1235 | 2025 |
| ZL800X1830 | DN300 | DN350 | DN25 | DN150 | 1450 | 1200 | 1190 | 980 | 1330 | 2025 |
Features
Ultrafiltration membrane element is the highest quality organic membrane element to ensure retention performance and membrane flux. The recovery rate of the system is high, and the quality of the products obtained is excellent, which can realize the high-efficiency separation, purification and high-fold concentration of materials. The treatment process has no phase change, no adverse effect on the composition of the material, and the separation, purification, and concentration process is always at room temperature. It is especially suitable for the treatment of heat-sensitive substances, which completely avoids the damage of high temperature to biologically active substances. , Effectively retain the biologically active substances and nutrients in the raw material system.
Packing and Delivery
1. Waterproof packing with the international export standard by 20ft, 40ft, 40hp container. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
2. The whole plant machinery size are large as normal, so we will use Waterproof cloth to pack all of them. The motor, gear box or other easily damaged parts, we will put them into box. We have a professional shipping department, they will try their best to save your container quantity.
FAQ:
Q: Are You Trading Company Or Manufacture?
A: We Are Both Manufacture And Trading Company. We Have Over 30 Years' Professional Experience As a Waste Water Treatment Equipment Manufacturer And Engineering Service Enterprise.
Q: How Can I Find The Suitable Model?
A: Please Provide Flow Rate, Solids Content And Sludge Type, or directly contact us by the clicking the “contact” icon. We Can Assist You In Model Selection.
Q: Where Is Your Factory Located?
A: Yixing City, We are in the famous city of environmental protection equipment ,professional for Sludge screw press dewatering Machine ,Which Is Very Close To Shanghai With Only Less Than 3 Hours' Driving. Welcome for your visiting.
